Birm Iron Filter System with 9

Birm Iron Filter System with 9" X 48" Tank & Fleck 5600SXT Digital Control Valve

Birm Iron Filter System with 9

Birm Iron Filter System with 9" X 48" Tank & Fleck 2510SXT Digital Control Valve

Birm Iron Filter System with 9" X 48" Tank & Fleck 2510 12 Day Timer

$675.00

Helps to Remove
Iron and Manganese

Advantages
•Under the proper conditions, no chemicals to purchase for maintenance. Regeneration not required.
•Iron removal efficiency is extremely high.
•Negligible labor cost: only periodic backwashing required.
•Durable material with a long life and wide temperature range.
•Weighs only 36-38 lbs./cu.

Click to Read More about Birm

*Shipping Included!*
Availability: In stock
SKU
BIRM2510T9x48
Birm is a Granular filter media used for the removal of Iron and Manganese. It is an efficient and economical method of removing dissolved iron and manganese compounds from raw water supplies. Birm works at maximum efficiency with pH levels of 7.2 or greater.

This system includes:
  • Fleck 2510 12-Day Control valve
  • 9x48 Fiberglass Mineral Tank
  • 1" stainless steel by-pass
  • 1 Cu. ft of Birm
  • 1 Sleeve of gravel
  • 1.05" Riser Tube
  • Funnel and Cap

Birm is an efficient and economical media for the reduction of dissolved iron and manganese compounds from raw water supplies. It may be used in either gravity fed or pressurized water treatment systems. Birm acts as an insoluble catalyst to enhance the reaction between dissolved oxygen (D.O.) and the iron compounds. In ground waters the dissolved iron is usually in the ferrous bicarbonate state due to the excess of free carbon dioxide and is not filterable. Birm, acting as a catalyst between the oxygen and the soluble iron compounds, enhances the oxidation reaction of Fe++ to Fe+++ and produces ferric hydroxide which precipitates and may be easily filtered. The physical characteristics of Birm provide an excellent filter media which is easily cleaned by backwashing to remove the precipitant. Birm is not consumed in the iron removal operation and therefore offers a tremendous economic advantage over many other iron removal methods.

Other advantages of Birm include; long material life with relatively low attrition loss, a wide temperature performance range and extremely high removal efficiency. Negligible labor costs are involved because Birm does not require chemicals for regeneration, only periodic backwashing is required.

When using Birm for iron removal, it is necessary that the water: contain no oil or hydrogen sulfide, organic matter not to exceed 4-5 ppm, the D.O. content equal at least 15% of the iron content with a pH of 6.8 or more. If the influent water has a pH of less that 6.8, neutralizing additives such as Clack Corosex®, Calcite or soda ash may be used prior to the Birm filter to raise the pH. A water having a low D.O. level may be pretreated by aeration.

More Information
Model # BIRM2510T9x48
Manufacturer Fleck
Shipping Weight 152
Flow Rate 0
Material Birm
Size 9" X 48"
Control Valve 2510 12 Day Timer
Warranty Lifetime Mineral Tank Warranty, and 5 Year Control Valve Parts
